One roll 12" x 39" of .060" N-8094 Gasket Material
N-8094
Syntheseal / Non asbestos Gasket Material
Description:
N-8094 is a medium density material that conforms well to irregular flange surfaces and has very good crush resistance at high flange pressures. It is intended for sealing oils, fuels, and water in applications with short duration maximum temperatures up to 350 degree F (180 degree C).
Specification Properties
Property Value Method
Density, g/cc(lb/cu.ft) 0.87 (54) (min) ASTM F 1315
Compressibility, % at 34.5MPa 28-42 ASTM F 36
Recovery, % 20 (min) ASTM F 36
Tensile Strength, AMD, MPa(psi) ASTM F 152
1.0mm Gauge and Higher 6.9(1000) (min)
less than 1.0mm gauge 8.62(1250) (min)
Fluid Resistance, IRM903 Oil ASTM F 146
Change in Tensile Strength, % 30 (max)
Change in Thickness, % 7(max)
Change in Compressibility, % 30-45
Fluid Resistance, Fuel B ASTM F 146
Change in Thickness, % 7(max)
Change in Weight, % 25-50
Binder Type Nitrile Butadiene
Remarks
Specification values determined by the test methods required for ASTM F-104, Type 7 materials
